The Air 30 by Primus delivers when you need energy. Hands down the best energy choice for off grid land based applications in high wind environments.
Efficient operation across a wide range of wind speeds makes the Air 30 perfect for pairing with solar to offset seasonal variation, delivering more consistent energy.
See Features below:
-
High-quality, third-party tested components for reliability and safety
-
Pair with solar PV for redundant energy production year-round
-
Advanced microprocessor technology for superior performance and high wind protection without mechanical braking
-
Lightweight design is simple and easy-to-install; integrated power electronics for plug-and-play operation
-
Produces 30 kWh of energy a month* for land-based, high wind applications
Specification
| Energy | Approx. 30 kWh/mo at 5.8 m/s (13 mph) |
|---|---|
| Swept Area | 1.07 m2 (11.5 ft2) |
| Rotor Diameter | 1.17 m (46 in) |
| Weight | 5.9 kg (13 lb) |
| Shipping Dimensions | 686 x 318 x 229 mm (27 x 12.5 x 9 in) 7.7 kg (17 lb) |
| Startup Wind Speed | 3.58 m/s (8 mph) |
| Voltage | 12, 24 and 48 VDC |
| Turbine Controller | Mircoprocessor-based smart controller |
| Body | Permanent mold cast aluminum |
| Blades | (3) Injection-molded composite |
| Alternator | Permanent magnet brushless |
| Overspeed Protection | Electronic torque control |
| Survival Wind Speed | 49.2 m/s (110 mph) |
| Mount | 1.5 in schedule 40 pipe 48 mm (1.9 in) outer diameter |
| Wind Speed Operating Range | 3.6-22 m/s (8-49 mph) |
| Optimum Wind Speed Range | 11-15 m/s (25-32 mph) |
Product Guide
Primus Windpower Air Series Manual
The body of the Primus Windpower Air 30 is constructed of permanent mold cast aluminum and the three blades are made of carbon molded composite.
The generator can be used for multiple types of off-grid power applications including telecom, security systems, cabins, tiny homes, and trailers. It can also be used in conjunction with a solar system to supplement battery charging.
Requiring only an 8mph wind for startup, the AIR 30 will produce 30 kWh per month with an average wind speed of 13 miles per hour.
It comes with a built-in microprocessor controlled charge controller and the option of using an external load diversion controller.
The wind generator cannot be connected directly to a power inverter. It must be used to charge a 12-volt battery bank.
Your inverter will get its power from the batteries.
Comes with a 5-year manufacturer's warranty.
Primus Wind Turbine Applications Chart
